Arthur Ultimate

Arthur IX Ultimate

Beat the system

Arthur Ultimate redefines your riding experience and rises above the status quo. Arthur speaks Ultimate and ensures perfect communication within the installed systems. By offering full integration of the Mahle X20 motor with Pinion Smart.Shift, it enables a perfectly functioning ecosystem. No compromise on equipment and therefore no compromise on performance.

high torque

gears

pinion smart.shift

16.2

lightweight

Arthur Ultimate redefines your riding experience and rises above the status quo. Arthur speaks Ultimate and ensures perfect communication within the installed systems. By offering full integration of the Mahle X20 motor with Pinion Smart.Shift, it enables a perfectly functioning ecosystem. No compromise on equipment and therefore no compromise on performance.

jade green

technology highlights

Experience amazing riding dynamics thanks to the lightweight, slim yet powerful Mahle X20 system. At the touch of a button, you can control the maximum 55 Nm torque in three performance levels with the new Human Machine Interface. Connect Arthur Ultimate to the Mahle app to customize the riding characteristics and display data of your trip.

Compact yet powerful.

Cutting-edge technology seamlessly integrated. A lightweight hub motor, the battery concealed in the down tube and just one button on the top tube for control - every component of the Mahle X20 system fits perfectly into the Schindelhauer design language. Arthur Ultimate gives you the freedom to choose the riding style that suits you at any time. Whether electric or with your own power.

Lightweight motor

The reliable, ultra-light rear hub motor from Mahle weighs just 1.39 kg and is barely noticeable. Up to 55 Nm of torque ensure a strong performance.

3 performance levels

With the Human Machine Interface of the Mahle X20 system, you have three performance levels at your disposal - while you can always keep an eye on the battery charge level. Your own performance level starts at over 25 km/h, which has never felt so natural with Arthur Ultimate.

Smart app control

Connect Arthur Ultimate to the Mahle app to adjust your preferred motor settings even further, switch between auto and manual lighting, create routes, track and analyze your rides, check the battery status and install updates.

Battery in the down tube

Depending on the performance level, the integrated 250 Wh battery will get you between 50 and 80 km. A full charge takes around 3 hours. The battery can be removed for servicing.

Zero maintenance

Oiling, greasing and rusting are a thing of the past.

Highly efficient

With a higher wattage, the efficiency is higher compared to the chain.

Long life span

The Gates Carbon Drive lasts about 3-4 times longer than a chain.

Stay clean

Due to the lack of oil, it keeps your trousers away from dirt.

Super quiet

No chain - No more chain running noises.

Lightweight

The Gates Carbon Drive weighs 20% less than a classic chain.

Precise shifting via semi-automatic.

Pinion Smart.Shift fully integrated for the first time. Thanks to the new technically advanced integration of the Mahle X20 system with Pinion Smart.Shift, you can experience all the benefits of electronic shifting. Based on your preferred cadence, Pinion Smart.Shift automatically engages the matching gear at traffic lights. You can change the gear ratio manually at the touch of a finger on the TRP shift/brake lever unit (Brifter).

Pinion Ci-Line with 9 gears

The premier class of bicycle gears has been developed by former Porsche engineers and impresses with its exceptional durability, reliability and precision. Thanks to its central positioning, an optimum center of gravity is ensured. With 9 gears, you have a spread of 568% at your disposal.

Shift in 0.2 seconds

Smart.Shift stands for a new era of precision and speed in electronic shifting. In just 0.2 seconds, you can reliably control your transmission either semi-automatically or manually.

Semi-automatic with Start.Select and Pre.Select

Starting at traffic lights has never been more effortless. With Start.Select, you always start off in your preferred gear. Pre.Select is the perfect choice if you always want to be in the right gear automatically while riding. Simply define your desired cadence in the Pinion Smart.Shift app.

Manual shifting at your fingertip

Whether individual successive gears or entire jumps, you get direct feedback at all times and therefore a secure feeling when shifting gears at the hydraulic shift/brake lever "Brifter".

Turn on the lights

Consistent with functionality and design. TThe LightSKIN built-in light handlebar has undergone further evolution with the introduction of H1. H1 represents a complete redefinition of optical technology in bicycle lights, offering users an unparalleled experience. Experience the new lens from LightSKIN, achieved through highly precise optic technology.

LightSKIN - H1 Dropbar

The next stage of evolution: thanks to new lens technology, the integrated LightSKIN LED handlebar is three times as bright as its predecessor and offers even better illumination thanks to its central positioning.

LightSKIN - integrated LED rear light

Five LEDs, recessed in the seat post, ensure optimum safety in road traffic from all angles.

More Highlights

Hydraulic disc brakes

TRP - HYWIRE

Continental Grand Prix tires

Curana mudguards

Reliable protection against dirt and moisture

Brooks Cambium saddle

C15

Comfortable bar tape

Comfortable and gives you direct feedback.

Schindelhauer Pedals

Super-light and CNC-machined.

Meet the Family

Antonia

from 4.995,00 €

incl. VAT, plus shipping and handling

Transmission

Single speed

6-/9-speed Pinion C-Line

9-speed Pinion C-Line Smart.Shift

Features

mudguards by default

mudguards optional

pannier rack optional

Geometry

Classic

Step-through

The frame sizes listed are only a guide. Finding the right sized frame for you depends on things like your height, personal preferences and riding style. We always recommend taking a test ride at one of our dealers.,

Frame Size	Body Height	Inseam Length
S (53)	174-189	80-84
M (57)	183-197	84-88
L (61)	191-206	88-95

Frame Size	53 (S)	57 (M)	61 (L)
A size c-t (mm)	530	570	610
B top tube horiz. (mm)	600	620	640
C head tube (mm)	165	180	200
D chain stay (mm)	449	449	449
E head tube angle (°)	72,5	72,5	72,5
F seat tube angle (°)	73	73	73
G wheelbase (mm)	1081	1101	1121
H standover height (mm)	804	829	857
I Reach	432	449	463
J Stack	576	590	609
headset	1 1/8 - 1,5	1 1/8 - 1,5	1 1/8 - 1,5
seatpost size (mm)	31,6	31,6	31,6

Suitable accessories

Anti Theft Sets

Hexlox intelligently protects your components from theft. Whether it's the wheels, saddle, seat post or stem — the steel Hexlox cap prevents the access of Allen keys.
Learn more
Original Bell

Spurcycle from San Franciso might have designed the best bicycle bell in the world. Purist design and a powerful tone define the perfectly manufactured bell. Brass and stainless-steel are the dominating materials that make this bell such a wonderful addition to our bikes.
Learn more
Bottle Cage

Manufactured by traditional Japanese company MINOURA
Learn more

How to get your bike

Visit a dealer

We recommend to purchase your bike at one of our dealers. They will provide you with personal advice, a test ride and also offer you their best service after your purchase.

Discover bikes Bike leasing

Advance payment

Delivery to a dealer

Get your bike delivered to one of our dealers at no extra cost. They set up the bike for you professionally and will have it ready for pickup by arrangement. Select this option when ordering online.

Delivery to your home

You already know your desired bike and can't wait to conquer the streets? Get it delivered directly to your home – almost completely assembled. Simply follow the remaining steps in the manual.

FAQ

Where and how can I buy a Schindelhauer bike?

There are two options for buying a Schindelhauer bike:

1. Delivery directly to your home: If you cannot find a Schindelhauer specialist dealer near you via our dealer search, you can also have your desired model delivered directly to your home. The bicycle comes almost completely assembled. When setting up the bicycle yourself, please follow the instructions in the manual as well as the instructions for regular maintenance and care. Take your bicycle to a specialist workshop for regular inspection. We generally recommend, especially for e-bikes, that you have your bike assembled at a Schindelhauer specialist dealer or a specialist bicycle shop in your area.

2. Online purchase and delivery to a Schindelhauer dealer of your choice (Euro zone only): On request we can have your bike delivered to one of our dealers at no additional cost. This dealer will professionally assemble the bike for you free of charge and will make it available for collection by arrangement. In the online purchasing process, you will be given the option of selecting a Schindelhauer dealer near you as your delivery address. Any accessories ordered along with the bike, which are not part of the standard equipment, will be fitted directly in consultation with the dealer; assembly costs may be incurred here.

No Schindelhauer dealer nearby? In this case, the above-mentioned option of shipping directly to your home would be advisable. We are also happy to accept recommendations for future Schindelhauer dealers. If you are the owner of a bicycle shop or a customer of a recommendable shop, you are welcome to send us further information via info@schindelhauerbikes.de.

Purchase and delivery outside the euro zone? If you would like to purchase a Schindelhauer bicycle outside the euro zone, please first contact the nearest Schindelhauer dealer in your country, to be found via our dealer search. They may also be able to ship directly to you. If you cannot find a Schindelhauer dealer near you, please contact us via our contact form or via info@schindelhauerbikes.de.
